High-quality Durable Lift Cable Crane Flat Travelling Cable for Elevator Travel Cable With Steel Wire
Product Description
High-quality Durable Lift Cable Crane Flat Travelling Cable for Elevator Travel Cable With Steel Wire Product Description TVVB type Feature: 1. PVC isolation, PVC sheath 2. Rated voltage: 300/500VAC, 450/750VAC
3. Rated Temperature: 70ºC
TVVBG type Feature: 1. PVC isolation, PVC sheath 2. Rated voltage: 300/500VAC, 450/750VAC
3. Rated Temperature: 70ºC 4. With steel rope
TVVBP type Feature: 1. PVC isolation, PVC sheath 2. Rated voltage: 300/500VAC, 450/750VAC
3. Rated Temperature: 70ºC 4. With shielded communication cable
TVVBPG type Feature: 1. PVC isolation, PVC sheath 2. Rated voltage: 300/500VAC, 450/750VAC
3. Rated Temperature: 70ºC 4. With shielded communication cable and steel rope
Packaging & Shipping
Our Services Help Customers Source in China to reduce their cost
To provide customers with whole purchasing plan of elevator parts;
To find out the best conjunction point between quality and price in order to reduce costs for them. How to develop the suppliers for customers
To get customers' need through communicating.
To find out three to four manufactures of the corresponding parts according to the request of the customers. Ask price and get samples from the manufactures.
To visit the factory (acknowledge the production ability and quality control process).
Basing on the price, sample and visiting, recommend manufacturers to our customers. How to help customers order from the qualified suppliers
Follow the process of the order.
Send QC to inspect on site before shipping to acknowledge the product quality.
Transfer the response from the customers to the suppliers on time, and follow up the improvement. Special package services
Gather Sourced Parts for Dispatch (Less than one container Shpt. Service)
Help customers shipping products directly to the working site oversea:
Quick Response
Contact us if you need more details on Steel Wire. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Elevator Travel Cable、Travelling Cable. If these products fail to match your need, please contact us and we would like to provide relevant information.
3. Rated Temperature: 70ºC
TVVBG type Feature: 1. PVC isolation, PVC sheath 2. Rated voltage: 300/500VAC, 450/750VAC
3. Rated Temperature: 70ºC 4. With steel rope
| Cores | Cores*Section (m2) | Structure of Core | Maximum Overall Size (mm) |
| 24 | 24*0.75 | 24*24/0.20 | 48.0*10.0 |
| 36 | 36*0.75 | 36*24/0.20 | 57.0*9.5 |
| 40 | 40*0.75 | 40*24/0.20 | 56.0*9.5 |
| 48 | 48*0.75 | 48*24/0.20 | 70.0*9.5 |
3. Rated Temperature: 70ºC 4. With shielded communication cable
| Cores | Cores*Section (m2) | Structure of Core | Maximum Overall Size (mm) |
| 40 | 36*0.75+2*(2*0.75)P | 36*24/0.20+2*(2*24/0.20) | 56.0*9.5 |
| 52 | 48*0.75+2*(2*0.75)P | 48*24/0.20+2*(2*24/0.20) | 68.0*9.5 |
3. Rated Temperature: 70ºC 4. With shielded communication cable and steel rope
| Cores | Cores*Section (m2) | Structure of Core | Maximum Overall Size (mm) |
| 40 | 36*0.75+2*(2*0.75)P | 30*24/0.20+2*(2*24/0.20) | 68.0*9.5 |
| 52 | 48*0.75+2*(2*0.75)P | 30*24/0.20+2*(2*24/0.20) | 80.0*9.5 |
Our Services Help Customers Source in China to reduce their costTo provide customers with whole purchasing plan of elevator parts;
To find out the best conjunction point between quality and price in order to reduce costs for them. How to develop the suppliers for customers
To get customers' need through communicating.
To find out three to four manufactures of the corresponding parts according to the request of the customers. Ask price and get samples from the manufactures.
To visit the factory (acknowledge the production ability and quality control process).
Basing on the price, sample and visiting, recommend manufacturers to our customers. How to help customers order from the qualified suppliers
Follow the process of the order.
Send QC to inspect on site before shipping to acknowledge the product quality.
Transfer the response from the customers to the suppliers on time, and follow up the improvement. Special package services
Gather Sourced Parts for Dispatch (Less than one container Shpt. Service)
Help customers shipping products directly to the working site oversea:
Quick Response
Contact us if you need more details on Steel Wire. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Elevator Travel Cable、Travelling Cable. If these products fail to match your need, please contact us and we would like to provide relevant information. Product Categories : Traction System
